The new Siemens SN series plug-on neutral load center is the smart choice when value and quick installation are of highest priority. The SN series load centers include labor saving features such as the ability to accept plug-on neutral breakers, patented insta-wire and mounting trim tabs. These exclusive features make the SN series load center the best load center for the value minded contractor.
- SN series load center includes one factory installed ground bar
- Plug-on neutral, for quick and simple breaker installation
- Aluminum bus
- Spacious with over 4 inches of wire bending space
- Secure sturdy hook-rail provides a reliable connection
- Single phase load center
- 100% Neutral and Ground positions based on number of circuits
- NEMA Type 3R outdoor enclosure
- UL Listed
General
- Manufacturer Color/Finish: Gray
- Series Name: SN
- Type: Main breaker
Dimensions
- Depth (Inches): 4.88
- Height (Inches): 21
- Width (Inches): 14.25
Features
- Amperage: 100
- Buss Bar Construction: Aluminum
- Circuits: 24
- Cover Included: Yes
- Feed-Through Lugs: No
- Ground Bar Installed: Yes
- Mounting Type: Combination
- Number of Spaces: 12
- Orientation: Over/Under
- Paintable: Yes
- Phase Type: Single phase (120/240)
- Plug-On Neutral: Yes
- Usage: Service entrance
- Use Location: Outdoor
- Value Pack: No
- Value Pack Contents: N/A
- Voltage: 120
Compatibility
- Brand/Model Compatibility: Siemens
Warranty
- Warranty: 10-year
Certifications
- CA Residents: Prop 65 Warning(s): No
- Safety Listing: UL safety listing
Miscellaneous
- UNSPSC: 39121100
