This GE 20 Amp double pole Ground Fault circuit breaker with Self-Test has a tin-plated copper stab to create a reliable, permanent and corrosion resistant connection. It is used as a substitute to GFCI wall outlets allowing the customer to know exactly where to go (back to electrical panel) in the event of a tripped circuit. No more searching for the correct wall outlet to reset. The Self-Test functionality is a UL requirement on all GFCI devices commencing in June 2015. This variant of the GFCI ensures its ground circuitry is functioning properly by automatically running diagnostic testing on a periodic basis. Should a problem be detected, the circuit breaker will trip and will need to be replaced.
- Ground Fault protection for indoor and outdoor use
- Automatically performs Self-Test every 16 minutes
- Includes manual “push-to-test” button
- Unit provides protection against overloads, short circuits and ground faults
- Detects very low levels of electrical current leakage (ground faults) and acts quickly to shut off power, preventing serious shock
- Class A 5mA Ground Fault circuit interrupter
- Wire range is #14-8 AWG CU/#12-8 AWG AL
- UL Listed # E51075
- The warranty is one (1) year from first use or eighteen (18) months from delivery, whichever occurs first
General
- Series Name: Q-Line THQL
- Type: GFCI
Dimensions
- Power Capacity: 20-amp
- Width Measurement: 2-in
Features
- Circuit Breaker Voltage: 120
- Interrupting Amp Listing (Amps): 10
- Number of Poles: 2
- Phase: Single phase (120/240)
- Plug-On Neutral: No
- Surge Protection: No
Certifications
- CA Residents: Prop 65 Warning(s): No
Miscellaneous
- UNSPSC: 39121600
