Joist hangers are designed to provide support underneath the joist, rafter or beam to provide a strong a connection. Simpson Strong-Tie offers a diverse line of hangers to handle almost any application with top flange, concealed flange and field-skewable and slopeable options. LGUM high-capacity beam or girder hangers are for concrete or masonry applications. Installation is made easier using Simpson Strong-Tie Strong-Drive SDS screws (provided) into the wood member and Titen HD anchors (provided) into the masonry.
- Attach hanger to a concrete or grouted CMU wall using Titen HD anchors
- Titen HD is not recommended for exposed exterior applications
- Provide moisture barrier between beam and wall per jurisdictional requirements
- Seat width: 4-15/16-in
- Height: 9-1/4-in
- Nominal joist size: Triple 2×10
- Made from 12-gauge steel
- Galvanized (G90) for extra corrosion resistance
- Install with Strong-Drive SDS Heavy-Duty Connector screws and Titen HD anchors (included)
General
- Finish: G90 galvanized
- Manufacturer Color/Finish: Zinc Galvanized, G90
- Type: Girder hanger
Dimensions
- Actual Length (Inches): 9.313
- Actual Width (Inches): 10.375
- Common Measurement (W x L): 2-in x 10-in
- Depth (Inches): 4.281
- Maximum Size: Triple 2×10
- Minimum Size: Triple 2×10
Features
- Adjustable: No
- Fasteners Included: Yes
- Gauge: 12
- Material: Steel
- Materials Connected: Other
- Members: Triple
- Multi-pack: No
- Nails Required: None
- Package Quantity: 1
- Skewed: No
- Sloped: No
- Warranty: Limited lifetime
Certifications
- ACQ Approved: No
- CA Residents: Prop 65 Warning(s): No
Miscellaneous
- UNSPSC: 30103600
