SharkBite large-diameter push-to-connect fittings are the fastest way to connect PEX, copper, CPVC, PE-RT, or HDPE pipe in any combination. They are available in 1-1/4 in., 1-1/2 in. and 2 in. CTS sizes. No soldering, clamps, unions, glue, or special tools are required. Simply insert the pipe and the teeth bite down and grip tight, while a specially formulated O-ring compresses to create a watertight seal. Changes can easily be made by rotating the fitting after installation. Removing the fitting is just as fast using a disconnect tool so fittings can be easily changed or reused. Designed with stainless steel gripping teeth for a secure connection, a chlorine-resistant O-ring for a long-lasting seal, and backed by a 25-year warranty.
- Fastest way to connect PEX, copper, CPVC, PE-RT, or HDPE pipe
- Requires no special tools to install on hot or cold-water lines
- Maximum pressure rating 200 PSI
- Maximum temperature rating 200 degrees F
- PEX stiffener required when working with PEX pipe (sold separately)
- Approved for underground and behind-the-wall applications with no access panels (wrapping required when burying underground
- Can be installed on wet or dry lines and pressure tested immediately, no waiting on soldered joints to cool or solvents to dry
- When connecting to PEX pipe, a stiffener (SBTL35, SBTL41, SBTL54) is required
- Fitting can be removed with a large diameter disconnect tool (UXLDC35, UXLDC41, UXLDC54)
General
- Series Name: N/A
Dimensions
- Inlet Diameter: 1-1/2-in
- Inlet Size in Inches: 1-1/2-in
- Outlet Diameter: 1-1/2-in
Features
- Application: Potable Water
- Drain/Vent: No
- Inlet Thread Type: Push-to-connect
- Material: Brass
- Maximum Pressure: 200 PSI
- Outlet Thread Type: Push-to-connect
- Package Quantity: 1
- Warranty: 2-year limited
Compatibility
- Compatible Pipe Material: Multi-Purpose
Certifications
- CA Residents: Prop 65 Warning(s): Yes
- Complies with Federal Lead Guidelines: Yes
Miscellaneous
- UNSPSC: 40141600
