Peerless-AV’s In-Wall Boxes are designed to provide ultimate flexibility for any installation. The removable trim ring allows the installation to take place before or after drywall is installed. Flexible mounting options allow securement by two studs, a single stud or drywall only. Removable mounting plates reduce installation time by allowing an installer to complete wiring terminations outside the In-Wall Box.
Installation
Installs between 16″ (406mm) stud centers, to a single stud or directly into a drywall opening
Knock-outs
Knock-outs for 3/4″, 1.0″, 1.25″ and 1.5″ conduit. Cut-Out Dimensions: 14.4″ x 14.4″ (365 x 365mm). Knock-outs provide the ability to mount up to four single gang outlets. Compatible with RACO 420 gang box or equivalent.
Cable tie locations
Integrated cable tie locations
UL 2416 listed
Adjustable Trim Ring allows use of 3/8″ – 3/4″ drywall thickness
Specifications
Key Specs
- Color: White
General
- Brand: Peerless-AV
- Model Number: IB14X14-W
- Product Name: 14×14″ In-wall Box
Features
- Accessory Type: In-Wall Box
- Compatibility: 14×14″ In-wall Box – White
Dimensions
- Product Height: 15 4/5 inches
- Product Width: 15 4/5 inches
- Product Depth: 15.75 inches
Warranty
- Warranty – Parts: 5 years limited
- Warranty – Labor: 5 years limited
Specifications
- UPC: 735029332756
