The NR90AD(S1)M framing nailer drives paper collated nails from 2″ up to 3-1/2″ in length and features Metabo HPT’s next generation “industrial design.” Weighing only 7 lbs, it is easy to use all day, while still providing the power of a bulkier, heavier nailer. It can be used for floor and framing, truss build-up, window build-up, sub flooring, roof decking, wall sheathing and housing construction. Allows for quick transitions between sequential and contact nailing with the simple flip of a switch.
- APPLICATIONS: Great for floor and framing, roof decking and housing construction
- LIGHTWEIGHT: Only 7 lbs and well- balanced for ease of maneuverability and less user fatigue
- SELECTIVE ACTUATION: Allows for quick transitions between sequential and contact nailing with the simple flip of a switch
- FASTENERS: Accepts 2-in up to 3-1/2-in paper collated framing nails
- DEPTH ADJUSTMENT: Easy tool-less adjustment dial allows for countersink or flush driving nails into a variety of materials
- LOADING: Two-step nail loading makes fastener replenishment quick and easy
General
- Type: Framing
Dimensions
- Depth Control: Tool free
- Inlet Size in Inches: 3/8-in
- Magazine Capacity: 86
- Maximum Nail Diameter: 0.162-in
- Maximum Nail Length: 3-1/2-in
- Minimum Nail Length: 2-in
- Weight (lbs.): 7
Features
- Battery Recharge Time (Hours): 0
- Collation Material: Paper
- Collation Type: Angled
- Cordless: No
- Degree: 30
- Housing Material: Aluminum
- Jam Clearing: Tool free
- Maximum PSI: 120
- Pneumatic: Yes
- Power Source: Pneumatic
- Required Pressure (PSI): 70
- Strip or Coil: Strip
- Warranty: 5-year limited
Certifications
- ANSI Compliant: Yes
- CA Residents: Prop 65 Warning(s): Yes
