Zinsco circuit breaker by Connecticut Electric Type UBIZ. For use in Zinsco load centers that accept type R circuit breakers. ETL Listed. 10,000 AIC 1-pole twin 20A/20A clamshell packaged.
- Zinsco Replacement Circuit Breaker : R3820
- 2 – 1 Pole breakers in 3/4 in body (aka: twin, duplex, tandem)
- Intertek ETL Listing to UL Standard 489 for US and Canada -Molded case circuit breakers
- Manufactured New by Connecticut Electric
- For use in Zinsco Type R circuit breaker panels
- Plug in type
- 20/20 AMP, 120 VAC circuit breaker with 10,000 AIC
General
- Series Name: N/A
- Type: Tandem
Dimensions
- Power Capacity: 20-amp
- Width Measurement: 3/4-in
Features
- Circuit Breaker Voltage: 120
- Ground Fault Protection: No self test
- Interrupting Amp Listing (Amps): 10000
- Number of Poles: 1
- Phase: Single phase (120/240)
- Plug-On Neutral: Yes
- Surge Protection: No
- Warranty: 10-year
Certifications
- CA Residents: Prop 65 Warning(s): Yes
- Safety Listing: ETL safety listing
Miscellaneous
- UNSPSC: 39121600
