The 3/4″ ZW1017XLC Aqua-Gard® Thermostatic Mixing Valve is supplied with three female copper sweat tailpieces and union nuts, and utilized in both residential and most light commercial point-of-use installations to mix hot and cold water and reduce the hot water temperature in the distribution system to 122°F (50°C) or less. The ZW1017XL valve is suitable for installation in areas inaccessible to end users, and is recommended to be installed with a shut-off valve and thermometer in the tempered water line for safety and accuracy in conjunction with the ASSE 1070 device. Included with both inlet strainers and check valves, the ZW1017XL can also be installed in any position.
Series Name: AquaGard® Model ZW1017XL
Type: Thermostatic mixing valve
Material: Bronze
Application: Tub; shower and faucet
Inlet Thread Type: Copper sweat
Outlet Thread Type: Copper sweat
Maximum Pressure PSI: 145
Inlet Diameter: 3/4-in
Inlet Size in Inches: 3/4-in
Outlet Diameter: 3/4-in
CA Residents: Prop 65 Warning(s): Yes
Complies with Federal Lead Guidelines: Yes
Warranty: 1-year limited
UNSPSC: 30181800
