SharkBite oxygen barrier PEX is a cross-linked polyethylene tubing designed for use in radiant or hydronic heating applications. Oxygen barrier PEX has an oxygen barrier applied to the exterior of the pipe, which limits oxygen permeation through the tubing wall in hydronic heating applications preventing corrosion of metal parts in the heating system. PEX pipe is flexible and easy to work with, which reduces the number of fittings needed to complete a job; reducing cost and leak points. PEX is also extremely durable and corrosion/freeze resistant. SharkBite PEX is compatible with brass or plastic barb fittings using copper crimp ring or stainless steel clamp connection methods or push-to-connect fittings.
Color/Finish Family: Orange
Manufacturer Color/Finish: Orange
Sub Type: Oxygen-barrier PEX
Type: Pipe
Pipe Diameter: 1-in
Pipe Length: 300-ft
Code Approvals: ANSI/NSF 61, ANSI/NSF 14, CSA B137.5, ASTM F876, ASTM F2023, and ASTM F877
Common Use: Radiant heating
Material: PEX
Maximum Working Pressure (PSI): 160
Maximum Working Temperature (Fahrenheit): 200
Minimum Working Temperature (Fahrenheit): 33
Package Quantity: 1
PEX Type: PEX-C
CA Residents: Prop 65 Warning(s): No
Complies with Federal Lead Guidelines: Yes
Safety Listing: NSF safety listing
Warranty: 25-year limited
UNSPSC: 26121600
